Rainbow 780 HP is the latest “wavelength-flexible” femtosecond fiber laser, deli
Rainbow 780 HP is the latest “wavelength-flexible” femtosecond fiber laser, delivering an output power of >300 mW, pulse width <150 fs, and 24-hour power stability of <5 ‰, making it an ideal choice for fluorescence imaging, two-photon polymerization, and other applications.
| Parameter | Unit | Value |
|---|---|---|
| Operating Wavelength | nm | 780±10 |
| Pulse Width | fs | <150 |
| Repetition Rate | MHz | 80 |
| Average Power | mW | >300 |
| Power Stability | % RMS | <0.5 (24 h @ 25 °C) |
| Single-Pulse Energy | nJ | >5 |
| Polarization Extinction Ratio | dB | >20 |
| Beam Quality Factor | TEM00, M2<1.2 | |
| Output Method | Free-space Output | |
| Operating Temperature | °C | 10 – 45 |
| Dimensions | mm (L × W × H) | 445 × 300 × 134, 380 × 445 × 94 |
| Cooling Method | Air Cooling |
Output Spectrum
Pulse Autocorrelation
Output Power Stability
