532nm Picosecond Laser

Rb532 INT is derived from the Rb1064 INT with an external frequency-doub

在线咨询

产品介绍

Rb532 INT is derived from the Rb1064 INT with an external frequency-doubling module, delivering 532 nm ultrashort-pulse laser output. Thanks to its highly integrated optical-and-electronic architecture, the module is compact and portable, perfectly meeting researchers’ needs for system development.

Technical Advantages:

10 ps Green Output
Linear Polarization
Diffraction-limited Beam Quality

Applications:

LiDAR Ranging
Fluorescence Lifetime Imaging
Time-resolved Fluorescence

Technical Specifications:

Parameter	Unit	Value
Operating Wavelength	nm	532 ± 10
Pulse Width	ps	<15
Repetition Rate	MHz	20 – 50
Average Power	mW	>20
Power Stability	% RMS	<0.5 (24 h @ 25 °C)
Polarization Extinction Ratio	dB	>20
Beam Quality	—	TEM₀₀, M²<1.3
Output Method	—	Free-space, Ø ≈ 2 mm
Sync Signal	V	1 V @ 50 Ω
Operating Temperature	°C	15 – 35
Dimensions	mm (L × W × H)	204 × 127 × 70, 182 × 140 × 88
Cooling Method	Air Cooling	—

Test Data:

Typical Autocorrelation Trace.png

Typical Autocorrelation Trace

Output Spectrum.png

Output Spectrum

Power Stability.png

Output Power Stability

Beam Profile.jpg

Output Beam Profile

Dimensional Drawing:

532 nm Mechanical Dimensions.png
