The AOTF Acousto-Optic Tunable Filter is a plug-and-play dispersion device for s
The AOTF Acousto-Optic Tunable Filter is a plug-and-play dispersion device for supercontinuum light sources, capable of delivering 8 independent monochromatic channels within a single laser beam. Three different AOTF crystals cover the 400–2000 nm wavelength range. The standard output is free-space collimated, and an optional fiber coupler can be installed for fiber output.
| Model | AOTF | ||
|---|---|---|---|
| Crystal Name | Visible | Near IR | IR |
| Wavelength Range | 400–650 nm | 650–1100 nm | 1100–2000 nm |
| Spectral Bandwidth | 2–7 nm | 2–6 nm | 4–16 nm |
| Crystal Diffraction Efficiency | >90 % | ||
| Output Efficiency | >40 % | ||
| Polarization | Linear | ||
