PL Optics fiber-coupled spectrometer features SMA fiber coupling, wide spectral range, high optical resolution, and USB connectivity for precise spectral analysis in laboratory and industrial applications.
PLCTS launches its fiber spectrometers featuring a precision optical architecture and intelligent spectral analysis technology, using imported high-quality Richardson blaze gratings to achieve 20% higher sensitivity and 50% lower stray light, covering the UV to NIR range. Available in High-Resolution, High-Sensitivity, Cooled, and Mini versions, they serve both research and industrial applications. SpectroLink’s fiber spectrometers offer outstanding stability and scalability, delivering precise, reliable measurements across diverse fields.
| Model | Axmr-4000 | Axmr-UV | Axmr-NIR |
|---|---|---|---|
| Range | 200–1100 nm | 185–240 nm | 950–1200 nm |
| Detector | 3648-pixel CCD | ||
| Optical Resolution | <0.75 nm (best 0.1 nm) | <0.1 nm | <0.7 nm |
| Pixel Size | 8 μm × 200 μm | ||
| Sensitivity | 130 photons/count @400 nm 60 photons/count @600 nm | / | / |
| SNR | 300:1 | ||
| Dark Noise | 12 RMS counts | ||
| Dynamic Range | 3.4×106 (system) | ||
| Integration Time | 4 ms–10 s | ||
| Stray Light | <0.05% @600 nm <0.1% @435 nm | / | / |
| Post-Cal Linearity | >99.8% | ||
| Slits (optional) | 10/25/50/100/200 μm | 10/25/50/100 μm | 25/50/100 μm |
| Platform | f/4 Symmetric Crossed Czerny–Turner | ||
| Fiber Connector | SMA905, NA 0.22 | ||
| Size (mm) | 149 × 105 × 46 | ||
| Weight | 840 g | ||
|
|
| Model | Axns-2000 | Axns-UV | Axns-NIR |
|---|---|---|---|
| Range | 200–1100 nm | 185–240 nm | 1000–1550 nm |
| Detector | 2048-pixel CCD | ||
| Resolution | <0.87 nm | <0.1 nm | <0.7 nm |
| Pixel Size | 14 μm × 14 μm | ||
| QE | 80% | 80% | / |
| SNR | ~450:1 | ||
| Exposure | Yes | ||
| Int. Time | 17 ms–10 s | ||
| Slits (opt.) | 10/25/50/100/200 μm | 10/25/50/100 μm | 25/50/100 μm |
| Platform | f/4 Sym. Czerny–Turner | ||
| Size (mm) | 149 × 109 × 50 | ||
| Weight | 1000 g | ||
| Model | Axtc |
|---|---|
| Range | 200–1100 nm |
| Detector | 2048-pixel CCD |
| Cooling | 20 °C below ambient |
| Pixel Size | 14 μm × 14 μm |
| SNR | 1000:1 |
| AD | 16-bit |
| Integration Time | 17 ms–60 s |
| Slits (opt.) | 10/25/50/100 μm |
| Platform | f/4 Sym. Czerny–Turner |
| Fiber Connector | SMA905, NA 0.22 |
| Size (mm) | 192 × 109 × 58 |
| Weight | 1790 g |
| Model | Pton |
|---|---|
| Range | 200–1100 nm |
| Detector | 3648-pixel CCD |
| Optical Res. | <1 nm |
| Pixel Size | 8 μm × 200 μm |
| SNR | 300:1 |
| Dynamic Range | 2×109 (system) |
| Integration Time | 4 ms–10 s |
| Slits (opt.) | 10/25/50/100/200 μm |
| Platform | f/4 Sym. Czerny–Turner |
| Fiber Connector | SMA905, NA 0.22 |
| Size (mm) | 89 × 63.9 × 36.2 |
| Weight | 170 g |
For full details, please visit our official store’s Fiber Spectrometer section: www.plctss.com
