SC-PRO is our newly launched high-power supercontinuum light source, covering a spectral range of 430–2400 nm, with power up to 8 W (optional high power 10–20 W), repetition rate adjustable from 10 kHz to 80 MHz, and customizable external triggering from 1 MHz to 80 MHz; at low repetition (1 MHz) it delivers pulse energy >1 µJ, making it ideal for super-resolution imaging, nonlinear detection, OCT, nanophotonics, fluorescence lifetime spectroscopy, and more.
Technical Advantages:
- Total Power: >8 W (optional 10–20 W)
- Spectrum Range: 430–2400 nm
- External Trigger: 1–80 MHz optional
- Repetition Rate: 10 kHz–80 MHz
- Pulse Energy: >1 µJ
- Single-mode Output
Applications:
- Photocurrent Microscopy
- Nanophotonics
- Fluorescence Spectroscopy & Imaging
- Super-resolution Imaging (STED)
- Optical Coherence Tomography (OCT)
- Photoacoustic Microscopy
Technical Parameters:
| Model | SC-Pro |
|---|
| Total Power | >8 W |
| Repetition Rate | 10 kHz–80 MHz adjustable |
| Visible Power | >1000 mW |
| Spectrum Range | 430–2400 nm |
| Power Stability | <1 % |
| Pulse Width | ~100 ps |
| Beam Diameter & Quality | ~2 mm @ 633 nm, M² <1.1 |
| Divergence Angle | <1 mrad |
| Polarization | Unpolarized |
| Fiber Length | 1.5 m |
| Control Interface | USB |
| Sync Output (SMA) | NIM signal, 0–1 V |
| External Trigger (SMA) | 100 kHz–2 MHz or 1 MHz–80 MHz, 0–5 V |
| Power Requirements | 100–240 V, 50/60 Hz |
| Dimensions | 442 × 301 × 176.5 mm,<20 kg |
| Optional Configurations | Total Power: 10–20 W Pulse Width: 50 ps Repetition Rate: 0.1–200 MHz |
