Non‐planar ring oscillator (NPRO) laser

SLPR Series Non-Planar Ring Oscillator (NPRO) Lasers employ a monolithic laser

在线咨询

产品介绍

SLPR Series Non-Planar Ring Oscillator (NPRO) Lasers employ a monolithic laser crystal combined with a magnetic field to create a unidirectional non-planar ring cavity, delivering kHz-class ultra-narrow linewidth, low noise, and high frequency stability continuous single-frequency output. Robust packaging, extensive burn-in testing, and real-world integration verification ensure outstanding stability and performance.

A typical non-planar ring oscillator (NPRO) laser features a spectral linewidth < 5 kHz and relative intensity noise < -140 dB/Hz at 10 MHz, thanks to its internally stabilized oscillator and matching low-noise circuitry that effectively suppress self-relaxation oscillations.

Key Advantages:

Stable NPRO module
kHz-class ultra-narrow linewidth
Temperature & PZT tuning
Fiber-coupled or free-space output
User-friendly, ideal for OEM integration

Applications:

Confocal microscopy imaging
LiDAR seed source
Coherent communication & metrology
Laser spectroscopy
Passive sonar

Technical Specifications:

Item	Unit	Specification
Central Wavelength	nm	1064.4
Operating Mode	-	Continuous
Output Power	mW	50 / 250
Frequency Stability	MHz/min	3
Linewidth	kHz	< 5
Power Stability	-	2 % (12 h @ 25 °C)
Beam Quality M²	-	< 1.2
Frequency Stability	MHz/min	3
Temperature Tuning Range	GHz	30
Temperature Tuning Coefficient	GHz/K	3
PZT Tuning Range	MHz	±100
PZT Tuning Coefficient	MHz/V	3
PZT Tuning Bandwidth	kHz	1.4
Output Type	-	Free-space or fiber-coupled output
Fiber Connector	-	FC/APC connector
Operating Temperature	°C	15 – 30
Cooling Method	-	Air cooling
